Power Mixer Yamaha EMX 2 12channel ORYGINAL

Merek: Yamaha | Lihat selengkapnya produk Audio Interface dari merek Yamaha
    • InputsTOTAL 10ch : Mono (MIC/LINE):4, Stereo(LINE):3
    • Phantom powerCH1, 2 : +30V
    • OutputsSPEAKERS [L, R],
    • MONITOR OUT [L,R], SUBWOOFER OUT
    • Control and others
    • FOOT SW : Effect Mute on/off
    • BusStereo: 1, Effect: 1
    • Input Channel Function
    • PAD26 dB (CH1-4)Hi-ZSupported (CH4)EQ HIGH8kHz +15dB / -15dBEQ MID2.5kHz +15dB / -15dBEQ LOW100Hz +15dB / -15dB
    • On-board processors
    • DSPSPX Algorithm Reverb 4 programs, MASTER EQ (SPEECH to MUSIC), Feedback suppressor
    • On-board amplifiers
    • Maximum output power @4ohms1kHz THD+N less than 10% (CEA2006) : 250 W + 250 W, 1kHz THD+N less than 1% : 110 W + 110 WMaximum output power @8ohms1kHz THD+N less than 10% (CEA2006) : 170 W + 170 W, 1kHz THD+N less than 1% : 110 W + 110 WLevel Meter6points (-20, -6, 0 , +3, +6, LIMITER)
Sementara kehabisan stok
Rp7.956.250
Lihat tempat menjual
Dijual oleh: TITANIC_STORE Lihat selengkapnya produk Audio Interface dijual oleh TITANIC_STORE
  • Tersedia di DKI Jakarta
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • 14 hari pengembalian barang
  • Dukung pembuatan faktur
Deskripsi Produk Apa yang termasuk? Spesifikasi

Detail produk dari Power Mixer Yamaha EMX 2 12channel ORYGINAL

InputsTOTAL 10ch : Mono (MIC/LINE):4, Stereo(LINE):3
Phantom powerCH1, 2 : +30V
OutputsSPEAKERS [L, R],
MONITOR OUT [L,R], SUBWOOFER OUT
Control and others
FOOT SW : Effect Mute on/off
BusStereo: 1, Effect: 1
Input Channel Function
PAD26 dB (CH1-4)Hi-ZSupported (CH4)EQ HIGH8kHz +15dB / -15dBEQ MID2.5kHz +15dB / -15dBEQ LOW100Hz +15dB / -15dB
On-board processors
DSPSPX Algorithm Reverb 4 programs, MASTER EQ (SPEECH to MUSIC), Feedback suppressor
On-board amplifiers
Maximum output power @4ohms1kHz THD+N less than 10% (CEA2006) : 250 W + 250 W, 1kHz THD+N less than 1% : 110 W + 110 WMaximum output power @8ohms1kHz THD+N less than 10% (CEA2006) : 170 W + 170 W, 1kHz THD+N less than 1% : 110 W + 110 WLevel Meter6points (-20, -6, 0 , +3, +6, LIMITER)

General specifications

Frequency responseInput to SPEAKERS : +1 dB/-4 dB (40Hz to 20kHz), Input to MONITOR OUT : +0.5 dB/-1.5 dB (20Hz to 20kHz) , refer to the nominal output level @ 1 kHzTotal harmonic distortionInput to SPEAKERS : 0.2 % @ 13.8 W (40Hz to 20kHz), 0.4 % @ 23.2W (1kHz), Input to MONITOR OUT : 0.05 % @ +10 dBu (20Hz to 20kHz) 0.009 % @ +20 dBu (1kHz), (THD+N, Measured with 22 kHz LPF)
Hum & noise level
Equivalent input noise-115 dBuResidual output noiseInput to SPEAKERS : -68 dBu (40Hz to 20kHz, MASTER: min), Input to MONITOR OUT : -99 dBu (20Hz to 20kHz, MONITOR: min)Crosstalk-80 dB (1 kHz, Measured with 1 kHz band pass filter)
Protection circuit
Load protectionDC-faultAmplifier protectionOver heat protection, Over current protectionPower requirementsAC 100-240V, 50Hz/60HzPower consumption35W (Idle) / 90W (1/8 Power)
Dimensions
W375 mm (14.8")H147 mm (5.8")D220 mm (8.7")Net weight4.2 kg (9.3 lbs.)

Garansi resmi Yamaha

Apa yang ada di dalam kotak

1 UNIT Power Mixer Yamaha EMX 2 12channel ORYGINAL

Spesifikasi lengkap produk

Merek: Yamaha
SKU: YA996ELAATKF7GANID-66714837
Jenis Garansi: Tidak Ada Garansi
Model: Power Mixer Yamaha EMX 2 12channel ORYGINAL
